SPECIFICATION
POWER SYSTEM
- Rated voltage: AC100-240V 50/60Hz
- Power: 950W
- DMX Connectors: 3 pin or 5 pin XLR IN / OUT
- Dimming: 0-100% linear dimming.
- Aperture: 5%~100% linear adjustment
- DMX Connectors: 3 pin or 5 pin XLR IN / OUT
- Power Connectors: Srandard power head input (Customizable)
OPTICAL SYSTEM
- Light source: 700W LED module (PF≥ 0.98)
- Light source life: 20,000 hours
- Color temperature: 8000K/6500K
- Dimming: 0-100% linear dimming
- CMY: 0-100% color mixing
- CTO: Linear color temperature adjustment (GL6: 2700K-8000K; GL6H: 2700K-6500K)
- Focus: Linear HD focusing, 2 meters to infinite sharpness adjustmen.
BODY FEATURE
- Working temperature: -20~45°C (Other customization option)
- Net weight: 42kg
- Gross weight: 52kg
- Carton size: 77*74*68cm
DYNAMIC EFFECTS
- Rotating gobo wheel: 6 plug-in rotating gobos + white color, with gobo shake and gobo arbitrary positioning function.
- Static gobo wheel: 8 fixed gobos + white color, with gobo dithering function.
- Animation wheel: Amination stand alone or combine gobos, bi-directional rotation at variable speed.
- Cutting wheel: 4 framing simultaneous blades with 0-90° rotation, chamfering system can generate dynamic cutting effects.
- Color wheel: 6 static color + white light, semi-color effect, color film with rainbow effect and two-way rotation.
- Prism: 3-facet and 6-facet prism with two-way rotation and prism positioning.
- Focusing: linear HD focusing, 2 meters to infinite sharpness adjustment.
- Strobe: 1-25 times / sec. Ultra-high speed strobe effect, optional random strobe and pulse strobe.
- Atomization: built-in atomizing mirror can generate soft wash effect adjustment, 0%~100% linear atomization.
- Spot uniformity: 90%
CONTROL SYSTEM
- Pan/Tilt: 540°/270°, automatic position correction system.
- Display & Control: 2.8-inch touch display screen with control pannel, Chinese and English can be switched at will.
- DMX: DMX offers both wired and wireless transmission, allowing for convenientand quick software upgrades.
- Control mode: USITT, DMX512, RDM, ArtNet, self-propelled, voice control, scene, master-slave mode.
- Control channel: 34/42 channels
