OPTICAL SYSTEM
Laser light source: 300W/360W/500W laser source
llluminance: 300W/280000LUX @20m
360W/320000LUX @20m
500W/480000LUX @20m
Luminous flux: 300W/21000LM
360W/32000LM
500W/44000LM
Light source life: 20000 hours
Color temperature: 7300K (color temperature can be customized)
Gogo angle: 0.6° (almost parallel light beam)
Optical lens: imported optical lens, light exit 200mm
Dimming: 0-100% linear dimming
Focus zoom: 0~100%Electronic linear HD focus
POWER SYSTEM
Voltage: AC80-245V 50/60Hz
Power: 380W/480W/620W
DMX connectors: 3 pin or 5 pin XLR IN/OUT
Power connectors: IP65 Power head input
DYNAMIC EFFECTS
Static Gobo : 17 + white gobos ,Variable speed jitter , Bi-direction flow dynamic effect
Color: 14+ white, bidirectional rotation, adjustable speed, can achieve half-color effect; (Color can be customized)
Prism: 8 prism can rotate in both directions, adjustable speed
Fog: support
Strobe: 0.5-20HZ strobe, adjustable speed
CONTROL SYSTEM
Pan/Tilt: 540°/270°,support pan and tilt reversal, adjustable speed
Intelligent control: display panel can record the device usage time, display device temperature, channel data and software version
Communication Design: DMX offers both wired and wireless transmission, allowing for convenient and quick software upgrades
Cooling system: Copper tube + fan cooling structure + temperature intelligent monitoring+Self-adjusting variable speed fan, Safety protection against excess temperature
Control protocol: DMX512, Self-propelled, voice-controlled, master-slave mode
Channel mode: 11CH/15CH
LIGHT BODY FEATURE
Housing: One-piece die-casting/aerospace magnesium alloy
Working Temperature: -45~45℃ (Other customization option)
Product size: 34.3x39.3x74.5cm
NW: 28.5kg
Carton size: 43x45x85cm
GW: 34kg
